ABB Plug In Power Relay, 230V ac Coil, 12A Switching Current, SPDT

Pluggable Interface Relays CR-M Series The CR-M series of pluggable interface relays from ABB are standard miniature relays with mechanical status indication. This series of relays also have an integrated test button for manual actuation and locking of output contacts, that can be removed if necessary.

Brand	ABB
Coil Voltage	230V ac
Contact Configuration	SPDT
Mounting Type	Pluggable
Switching Current	12A
Terminal Type	Fork, Screw, Spring
Length	21.2mm
Height	35.6mm
Depth	27.5mm
Contact Material	Silver Alloy
Minimum Operating Temperature	-40°C
Series	CR-M
Maximum Operating Temperature	+55°C
Dimensions	21.2 x 27.5 x 35.6mm

1SVR405611R3000 CR-M230AC2 with product code You can purchase ABB branded ABB Plug In Power Relay, 230V ac Coil, 12A Switching Current, SPDT product from our company.
