Arayüz Rölesi Modülü (SPDT) , PCB'ye Monte, Sıkıştırmalı Terminal, 8A 16,8 → 61,2V dc

Pluggable Interface Relays CR-P Series The CR-P series of pluggable interface relays from ABB are standard PCB relays that can be used for electrical isolation, amplification and signal matching between the electronic controlling, e.g. PLC (programmable logic controller), PC or field bus systems and the sensor/actuator level. These interface relays do not use additional internal protective circuits and therefore are overload-proof against short-time variations like current or voltage peaks.

Brand	ABB
Accessory Type	Relay Socket
Series	CR-M
Load Current Value	8A
Load Voltage Value250V
Terminal Type	Cage Compression, Fork, Screw
Length	12.7mm
Depth	29.0mm
Height	15.7mm
< strong>Contact Material	Gold Plated
Termination Type	Screw
Mounting Type	PCB Mount
Input Resistance< /strong>	1440Ω
Input Voltage Range	16.8 → 61.2V dc
Control Resistance	0.1Ω
Dimensions	12.7 x 29.0 x 15.7mm

1SVR405651R3100 CR-M4LS with product code You can purchase ABB branded Arayüz Rölesi Modülü (SPDT) , PCB'ye Monte, Sıkıştırmalı Terminal, 8A 16,8 → 61,2V dc product from our company.
