| Brand | ABB |
| Maximum Voltage | 24 → 240 V ac, 24 → 48V dc |
| Mounting Type | DIN Rail |
| Number of Timer Functions | Flash Start with OFF, Flash Start with ON, Impulse OFF with Auxiliary Voltage, Impulse ON, OFF Delay with Auxiliary Voltage, ON Delay, Pulse Former |
| Time Interval | 0.05 s → 100h |
| Number of Contacts | 1 |
| Number of Timer Functions | Multifunction |
| Contact Configuration | SPDT |
| Time Increment | Hour, Seconds |
| Maximum Current | 6A |
| Maximum Voltage | 250V |
| < strong>Switch Configuration | SPDT |
| Terminal Type | Screw |
| Power Supply | External |
| Width | 17.5mm |
| Minimum Voltage | 12V |
| Minimum Current Value | 100mA |
| Depth | 58mm |
| Length | 70mm |
| Maximum Operating Temperature | +60°C |
| Contact Material | Cadmium |
| Minimum Operating Temperature | -20°C |
| Origin | DE |
