Mean Well Switching Power Supply, RSP-100-24RS, 24V dc, 4.2A, 100.8W, 1 Output, 120 → 370 V dc, 85 → 264

Mean Well RSP-100 Series 100W AC-DC Enclosed Switch Mode Power Suuplies The Mean Well RSP-100 Series is a range of 100W AC/DC low profile, single output, enclosed type, switching power supply. The RSP-100 features up to date high performance circuit topology, PFC function and possess up to 88% high efficiency. This enclosed power supply can be cooled by free air convection from -30°C to +70°C, or +50°C ambient temperature under full load condition and even +70°C by suitable derat

Brand	Mean Well
Output Voltage
strong>	24V dc
Output Current	4.2A
Power Rating	100.8W
Number of Outputs1
Input Voltage	120 → 370 V dc, 85 → 264 V ac
Mounting Type	Chassis Mounted
Package Type
strong>	Closed
Length	179mm
Width	99mm
Depth	30mm
Efficiency	87%
Weight< /strong>	520g
Maximum Temperature	+70°C
Minimum Temperature	-30°C
Origin >	CN

RSP-100-24RS with product code You can purchase Mean Well branded Mean Well Switching Power Supply, RSP-100-24RS, 24V dc, 4.2A, 100.8W, 1 Output, 120 → 370 V dc, 85 → 264 product from our company.
