Mean Well Switching Power Supply, RSP-500-15RS, 15V dc, 33.4A, 501W, 1 Output, 120 → 370 V dc, 85 → 264 V

Mean Well RSP-500 Series 500W AC-DC Enclosed Switch Mode Power Suuplies The Mean Well RSP-500 Series is a range of 500W AC/DC low profile, single output, enclosed type, switching power supply. The RSP-500 features up to date high performance circuit topology, PFC function and possess up to 90.5% high efficiency. This enclosed power supply is cooled by the built-in long life DC fan from -30°C to +50°C ambient temperature and even up to +70°C by suitable derating. The RSP-500 features

Brand	Mean Well
Output Voltage
strong>	15V dc
Output Current	33.4A
Power Rating	501W
Number of Outputs	1
Input Voltage	120 → 370 V dc, 85 → 264 V ac
Mounting Type	Chassis Mounted
Package Type	Closed
Length	230mm
Width	127mm
Depth	40.5mm
Efficiency	88%
Maximum Temperature	+70°C
Minimum Temperature	-30°C
Weight	1.3kg

RSP-500-15RS with product code You can purchase Mean Well branded Mean Well Switching Power Supply, RSP-500-15RS, 15V dc, 33.4A, 501W, 1 Output, 120 → 370 V dc, 85 → 264 V product from our company.
