| Brand | Kingbright | |
| Screen Type | 7 Segments | |
| Number of Characters | 1 | |
| LED Colors | Red | |
| LED Color(s) | Red | |
| Number of Segments | 7 | |
| Dominant Wavelength | 630 nm | |
| Character Width | 22mm | |
| Character Height | 38mm | |
| Common Link | Cathode | |
| Mounting Type | Through Hole | |
| External Depth | 47mm | |
| External Width33.2mm | ||
| External Dimensions | 12.5 x 33.15 x 47mm | |
| External Height | 12.5mm | |
| Luminous Intensity | 210 mcd | |
| Face Color | Gray | |
| Forward Voltage | 2 V, 3.9 V | |
| Power Loss | 75 mW, 150 mW | |
| Operating Temperature Range | -40 → +85°C | |
| Forward Current | 30mA | |
| Maximum Operating Temperature | 30mA | |
| Maximum Operating Temperature | +85°C | |
| Minimum Operating Temperature | -40°C | |
| Minimum Operating Temperature | -40°C | |
| Decimal Direction | Right Side | |
| Origin | strong> | CN |
