| Brand | Vishay |
| Signal Type | Bidirectional |
| Diode Configuration | Single |
| Maximum Clamping Voltage | 43V |
| Minimum Breakdown Voltage | 26.7V |
| Mounting Type | Surface Mounted |
| Package Type | DO-214AA (SMB) |
| Maximum Reverse Standby Voltage | 24V |
| Number of Pins | 2 |
| Peak Impulse Power Loss | 600W |
| Maximum Peak Impulse Current | 14A |
| ESD Protection | Yes |
| < strong>Number of Elements per Chip | 1 |
| Minimum Operating Temperature | - 55°C |
| Dimensions | 4.57 x 3.94 x 2.24mm |
| Maximum Operating Temperature | +150°C |
| Altitude | 2.24mm |
| Width | 3.94mm |
| < strong>Test Current | 1mA |
| Maximum Reverse Leakage Current | 1µA |
| Length | 4.57mm |
