| Brand | Vishay |
| Signal Type | Bidirectional |
| Diode Configuration | Single |
| Maximum Clamping Voltage | 15.4V |
| Minimum Breakdown Voltage10V | |
| Mounting Type | Surface Mounted |
| Package Type | SMC |
| Maximum Reverse Standby Voltage | 9V |
| Number of Pins | 2 |
| Peak Impulse Power Loss | 1500W |
| Maximum Peak Impulse Current | 97.4A |
| Number of Elements per Chip | 1 |
| Minimum Operating Temperature | -55°C |
| Maximum Operating Temperature | + 150°C |
| Dimensions | 7.11 x 6.22 x 2.42mm |
| Maximum Reverse Leakage Current | 20µA |
| Length | 7.11mm |
| Test Current | 1mA |
| Height | 2.42mm |
| Width | 6.22mm |
